China Customized OEM Free Sample Gr23 Ti 6AL4V Eli Medical Titanium Bar Manufacturer Supplier Factory

Gr23 Ti-6Al-4V ELI Medical Titanium Bar Product Introduction

Gr23 Ti-6Al-4V ELI (Extra Low Interstitial) medical titanium bar is a premium grade alpha-beta titanium alloy specifically engineered for high-performance biomedical and surgical applications. As an advanced version of the widely-used Gr5 (Ti-6Al-4V), Gr23 features extra-low oxygen, nitrogen, carbon, and iron content, significantly improving its biocompatibility and fracture toughness. Manufactured under the strictest standards, it is ideal for load-bearing implants, orthopedic rods, dental fixtures, and trauma repair devices.

Shaanxi CXMET Technology Co., Ltd. proudly supplies high-purity Gr23 titanium bars tailored to meet the global medical market's stringent requirements. With over 20 years of metallurgical expertise and a legacy rooted in China's "Titanium Valley," our bars are widely acclaimed for their quality, consistency, and performance in the most demanding clinical environments.

Key Features of Gr23 Ti-6Al-4V ELI Medical Titanium Bar

Extra Low Interstitials: Significantly reduced oxygen and iron levels improve ductility and fracture toughness.
Superior Biocompatibility: Non-toxic, non-magnetic, and resistant to body fluids.
Corrosion Resistance: Exceptional resistance to bodily fluids and sterilization chemicals.
High Strength-to-Weight Ratio: Offers lightweight yet durable implant performance.
Excellent Fatigue Resistance: Ideal for dynamic, load-bearing applications such as orthopedic implants.
Sterilization Compatibility: Compatible with gamma, steam, and plasma sterilization.

Specifications of Gr23 Ti-6Al-4V ELI Medical Titanium Bar

Property	Specification
Grade	Gr23 (Ti-6Al-4V ELI)
Standard	ASTM F136 / ISO 5832-3 / AMS 4930
Diameter Range	6 mm – 120 mm
Length	Up to 6000 mm (customizable)
Surface Finish	Polished / Peeled / Ground
Tensile Strength	≥ 860 MPa
Yield Strength	≥ 795 MPa
Elongation	≥ 14%
Density	4.43 g/cm^3
Hardness (Rockwell C)	36 – 41

Gr23 Ti 6AL4V Eli Medical Titanium Bar factory

Applications of Gr23 Ti-6Al-4V ELI Medical Titanium Bar

Orthopedic implants (bone screws, plates, rods)
Spinal fixation systems
Dental implants and abutments
Trauma fixation devices
Surgical instruments
Maxillofacial reconstruction hardware

Working Environment of Gr23 Medical Titanium Bars

Gr23 Ti-6Al-4V ELI performs reliably in:

Long-term implantation in human body
High-humidity environments
Exposure to biological fluids
Gamma and steam sterilization processes
Dynamic mechanical loads and vibrations

Customization Options

Shaanxi CXMET offers comprehensive customization of Gr23 titanium bars, including:

Diameter and length specifications
Surface finishes: polished, pickled, or ground
Cut-to-length and machining services
Ultrasonic testing and third-party certification
Custom packaging for surgical-grade cleanliness

Main Advantages of Gr23 Ti-6Al-4V ELI Titanium Bar

Enhanced Fatigue Strength: Ideal for weight-bearing medical devices.
Low Elastic Modulus: More compatible with human bone than stainless steel.
Non-Allergenic: Contains no nickel or chromium.
Superior Osseointegration: Promotes bone growth around implants.
Global Certifications: Complies with ASTM F136, ISO 5832-3, and more.

Packaging and Logistics

Each Gr23 titanium bar is individually wrapped in medical-grade polyethylene and vacuum-sealed to ensure contamination-free delivery.

Custom wooden cases or foam-lined cartons
Moisture-proof, shock-resistant packaging
Clear labeling with heat number and test report
Air, sea, and courier shipping options available
Global delivery with export compliance documentation

Company Overview

Shaanxi CXMET Technology Co., Ltd., founded in 2005, is headquartered in China's Titanium Valley and operates a 50,000 m² facility. With 10 million RMB in registered capital and over 80 technical staff, we specialize in R&D, manufacturing, and exporting of non-ferrous and refractory metals, including titanium, nickel, tantalum, niobium, zirconium, molybdenum, and tungsten.

Our materials serve industries ranging from marine and oil & gas to medical, chemical, electronics, and aerospace. We uphold integrity, development, innovation, and excellence in service. Our mission is to create value for clients, benefit our enterprise, and support employee growth. With a forward-looking vision, we strive to innovate and lead the global titanium market.

Factory show

Production workshop

Production Equipments

Skin peeling machine

Sawing Machine

Planer

Wire Coiling Machine

Polishing Machine

Straightening Machine

Main Products

3D PRINTING PRODUCTS

ANODE PRODUCTS

TITANIUM PRODUCTS

NON-FERROUS METAL PRODUCTS

CUSTOMIZED PRODUCTS SERVICES

Why Choose Shaanxi CXMET Technology Co., Ltd.?

Extensive Product Range: From titanium to zirconium, covering Gr1 to Gr23.
Exceptional Processing Capabilities: CNC machining, precision forging, and ultra-sonic testing.
Relentless Innovation: Constant R&D in advanced medical materials.
Technological Leadership: Pioneering ELI-grade manufacturing processes.
Customized Solutions: Tailored sizes, tolerances, and surface treatments.

Founded in 2005 with a registered capital of 10 million RMB, Shaanxi CXMET operates on a 50,000 m² campus in China's renowned Titanium Valley. With more than 80 skilled technicians and two decades of market experience, we serve medical, marine, aerospace, chemical, and electronics sectors worldwide. Our culture of integrity, innovation, and excellence ensures enduring trust and partnership.

9001 Certification

ISO 13485

FAQ

Q1: What certifications do your Gr23 titanium bars meet?
A1: Our bars comply with ASTM F136, ISO 5832-3, and AMS 4930 standards and include full material test reports.

Q2: Can I order a small batch for testing or prototyping?
A2: Yes. We accept small orders for R&D and sampling purposes.

Q3: Do you offer third-party inspection services?
A3: Absolutely. SGS, BV, and other agencies can inspect upon request.

Q4: What is the lead time?
A4: Typically 7–15 days for stock sizes, 20–30 days for custom orders.

Q5: Can I get machined or finished bars for immediate use?
A5: Yes. We offer full machining and finishing services per your drawings.
